MPQ8039GN-AEC1-Z Images
- Manufacturer: MPS
- Category: Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers Package/Case: 8-SOIC (0.154, 3.90mm Width) Exposed Pad
- Description: IC HALF-BRIDGE PWM 8-SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MPQ8039GN-AEC1-Z Specifications:
- MfrPart.: MPQ8039GN-AEC1-Z
- Mfr: Monolithic Power Systems Inc. (MPS)
- Description: IC HALF-BRIDGE PWM 8-SOIC
- Product Category: Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers
- Package: Tape & Reel (TR)
- Series: Automotive, AEC-Q100
- PartStatus: Active
- OutputConfiguration: Half Bridge
- Applications: General Purpose
- Interface: PWM
- LoadType: Inductive
- Technology: Power MOSFET
- RdsOn(Typ): 100mOhm
- Current-Output/Channel: 4.25A
- Current-PeakOutput: 9A
- Voltage-Supply: 7.5V ~ 24V
- Voltage-Load: 7.5V ~ 24V
- OperatingTemperature: -40°C ~ 125°C (TJ)
- Features: -
- FaultProtection: Current Limiting, Over Temperature, UVLO
- MountingType: Surface Mount
- Package/Case: 8-SOIC (0.154, 3.90mm Width) Exposed Pad
- MPQ8039GN-AEC1-Z MPS, IC HALF-BRIDGE PWM 8-SOIC, Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers
MPQ8039GN-AEC1-Z, MPS authentic parts in stock from MPS authorized distributors, order today, can ship immediately.
