MP8042DF-LF-P MPS IC HALF BRIDGE DVR 20TSSOP
MP8042DF-LF-P Images
MP8042DF-LF-P Images
MP8042DF-LF-P
  • Manufacturer: MPS
  • Category: Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers Package/Case: 20-TSSOP (0.173, 4.40mm Width) Exposed Pad
  • Description: IC HALF BRIDGE DVR 20TSSOP
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
MP8042DF-LF-P Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
MP8042DF-LF-P Specifications:
  • MfrPart.: MP8042DF-LF-P
  • Mfr: Monolithic Power Systems Inc. (MPS)
  • Description: IC HALF BRIDGE DVR 20TSSOP
  • Product Category: Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers
  • Package: Bulk
  • Series: -
  • PartStatus: Obsolete
  • OutputConfiguration: Half Bridge (2)
  • Applications: General Purpose
  • Interface: PWM
  • LoadType: Inductive
  • Technology: Power MOSFET
  • RdsOn(Typ): 150mOhm
  • Current-Output/Channel: -
  • Current-PeakOutput: 5A
  • Voltage-Supply: 7.5V ~ 24V
  • Voltage-Load: 7.5V ~ 24V
  • OperatingTemperature: -40°C ~ 125°C (TJ)
  • Features: Status Flag
  • FaultProtection: Current Limiting, Over Temperature, UVLO
  • MountingType: Surface Mount
  • Package/Case: 20-TSSOP (0.173, 4.40mm Width) Exposed Pad
  • MP8042DF-LF-P MPS, IC HALF BRIDGE DVR 20TSSOP, Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers
