MP6536DU-LF-Z Images
- Manufacturer: MPS
- Category: Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers Package/Case: 40-VFQFN Exposed Pad
- Description: 26V, 5.5A, 3-CHANNEL HALF-BRIDGE
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MP6536DU-LF-Z Specifications:
- MfrPart.: MP6536DU-LF-Z
- Mfr: Monolithic Power Systems Inc. (MPS)
- Description: 26V, 5.5A, 3-CHANNEL HALF-BRIDGE
- Product Category: Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- OutputConfiguration: Half Bridge (3)
- Applications: DC Motors, General Purpose
- Interface: Logic, PWM
- LoadType: Capacitive
- Technology: Power MOSFET
- RdsOn(Typ): 140mOhm LS + HS
- Current-Output/Channel: 5.5A
- Current-PeakOutput: 5.5A
- Voltage-Supply: 5V ~ 26V
- Voltage-Load: 5V ~ 26V
- OperatingTemperature: -40°C ~ 125°C (TJ)
- Features: Bootstrap Circuit
- FaultProtection: Current Limiting, Over Temperature, Short Circuit, UVLO
- MountingType: Surface Mount
- Package/Case: 40-VFQFN Exposed Pad
- MP6536DU-LF-Z MPS, 26V, 5.5A, 3-CHANNEL HALF-BRIDGE, Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers
MP6536DU-LF-Z, MPS authentic parts in stock from MPS authorized distributors, order today, can ship immediately.
